Precision High Grip Machine Vice Code No.U-2121
Features
- UNIQUE Precision High Grip Machine Vices are compact, rigid & specially designed for Precision Milling, Grinding & CNC Operations.
- Unbreakable High Strength Ductile Iron Body.
- Grounded Top & Bottom.
- High-Quality Alloy Steel, Case Hardened HRC 60 ± 2 clamping jaws for high performance & longer life without wear.
- Tenon & tenon slots are provided for effortless truing of vice on the machine table.
- Accuracy in parallelism & squareness within 0.02 I 100 mm.
- Interchangeable Jaw Plates are available.
- Smooth & effortless handle movement to achieve high clamping force. (Max: 5000 Kg.)
Specifications
| SIZE IN INCHES | 6 | 6 |
|---|---|---|
| Width of Jaws in mm | 150 | 150 |
| Opening of Jaws in mm | 250 | 380 |
| Length Overall in mm | 360 | 530 |
| Height Overall in mm | 113 | 130 |
| Tenon Slot Size in mm | 20 | 20 |
| Weight (Approx) in kgs | 22 | 38 |
